Managing longitudinal strength at management level
1The lesson in plain words
As chief mate or master you plan sequences that keep stresses low throughout, watch them during cargo work, and protect the hull from fatigue over its life.
Rules behind the limits
Class rules, harmonised by IACS UR S11, set the strength of the hull girder. The permissible still water SF and BM in your loading manual come from them, with wave loads already allowed for. IACS UR S1 sets what the loading manual and loading instrument must contain. Bulk carriers and oil tankers built to the IACS Common Structural Rules follow the same idea.
Sequences, not snapshots
Plan every pour, discharge step and ballast change. Cargo can arrive faster than ballast can be discharged. Check every stage against applicable approved limits. Use harbour limits only where the loading manual permits them for the sheltered-water condition; otherwise use the applicable seagoing limits. Check the final condition against seagoing limits. Avoid a heavy hold next to an empty one unless the loading manual approves that pattern.
Monitoring
Compare actual quantities and draughts with the plan at agreed check points. Watch the midships draughts for growing deflection. Stop if the ship departs from the plan and re-run the loading instrument. Some large ships have hull stress monitoring: sensors that show real-time strain, useful in port and in heavy weather.
Fatigue
Fatigue is cracking caused by many cycles of stress, each well below the breaking stress. Repeated high still water BM, slamming and wave bending add up over the years. Keep BM well below 100 % when you can, and reduce speed or change heading in heavy head seas. Report and inspect cracks at hatch corners, bracket toes (where brackets meet plating) and the ends of longitudinals (lengthwise stiffeners).
Records and duties
Keep each loading condition, the instrument printouts and any deviations in the ship’s records. Under the ISM Code, company procedures should say who checks the plan and how. Hand over the plan and the stress status at each watch change during cargo work.
2Step by step
Building a safe loading sequence
- 1
Start from the loading manual’s approved sequences and the terminal’s real rates.
Approved patterns and real rates define what is possible.
- 2
Split each hold’s cargo into pours and match each step to the deballasting.
Cargo must not run ahead of ballast removal.
- 3
Check every stage in the loading instrument; use harbour limits only for sheltered conditions permitted by the loading manual.
Intermediate peaks are common.
- 4
Check the final condition against the seagoing limits and the stability criteria.
She must be fit for sea when she leaves.
- 5
Set shipboard check points for draughts, cargo and ballast quantities, and stresses.
Detect a mismatch before approved limits are exceeded.
- 6
At each check point compare draughts and quantities, re-run and adjust.
Shore figures and pump rates drift from the plan.
3Key data
- IACS UR S11
- Longitudinal strength standard behind permissible SF/BM
- IACS UR S1
- Content of the loading manual and loading instrument
- Harbour limits
- Only in sheltered conditions allowed by the loading manual
- Seagoing limits
- For departure, passage and arrival conditions
- Fatigue hot spots
- Hatch corners, bracket toes, ends of longitudinals
4Key points
- 1
Plan the whole sequence and check every stage, not only the end.
- 2
Match the cargo rate to the ballast rate, or stop the loading.
- 3
Changes in hull deflection call for a fresh check of the loading instrument and actual quantities.
- 4
Fatigue builds from repeated cycles: keep stress margins and ease heavy-weather loads.
5Frequent mistakes
Wrong: High loading rates are fine if the final condition is within limits.
Right: If cargo runs ahead of deballasting, intermediate stages can exceed limits. Match the rates or pause loading.
Wrong: Stresses below 100 % do no harm.
Right: Each cycle adds fatigue damage. Lower routine stress levels lengthen the hull’s life.
6Practice case & exam keys
A terminal loads at 6,000 t/h. Your plan needs 1 t of ballast out for every 3 t of cargo in, and your pumps discharge 1,500 t/h. What loading rate can you accept, and what do you do?
Show the answer
At 6,000 t/h the ballast must come out at 6,000 ÷ 3 = 2,000 t/h, but you can pump only 1,500 t/h. The fastest matching cargo rate is 1,500 × 3 = 4,500 t/h. Cap cargo intake at 4,500 t/h or use planned pauses; verify each stage against the approved limits.
Exam keys
- UR S11: strength standard; UR S1: loading manual and instrument.
- Every stage: applicable approved limits; harbour limits only as the manual permits in sheltered conditions.
- The cargo rate must match the deballasting rate.
- Fatigue comes from repeated stress cycles; inspect the hot spots.
